ECMO and COVID-19:
What Have We Learned?

Topic
Intensive Care
ECMO & Covid-19; ECMO during the Covid-19 pandemic
Topic
Intensive Care
Subscribe

ECMO and the
COVID-19 pandemic

The COVID-19 pandemic created unique challenges to test whether extracorporeal membrane oxygenation (ECMO) can increase the survival of critically ill patients with severe acute respiratory distress syndrome (ARDS). Emerging research shows a mortality benefit for COVID-19 patients with ARDS who are supported with ECMO. However, as healthcare resources are still very limited and there is a lack of consensus on patient selection across medical centers, only a small proportion of patients benefited from this potentially lifesaving strategy. Based on some lessons learned, we now know more about which types of patients benefit most and under which conditions.

The role of VV-ECMO in treating severe ARDS

ARDS is a critical respiratory condition where damaged lungs are unable to adequately transfer oxygen to blood, causing a dangerous drop in blood oxygen content that compromises the function of other organs. Mechanical ventilation can help many ARDS patients. However, in severe cases where lung compliance decreases dramatically, pressure-positive ventilation perpetuates the inflammatory insult, which is associated with several complications and poor clinical outcomes. Prior to the COVID-19 pandemic, it was noted that VV-ECMO (veno-venous extracorporeal membrane oxygenation) reduced mortality in patients who developed progressive, acute respiratory failure despite optimal support from conventional mechanical ventilation. Applying VV-ECMO maintains gas exchange and mitigates potential damage caused by mechanical ventilation, allowing the lungs to recover [4][5][6].

Approximately 40% of COVID-19 patients admitted to Intensive Care Units (ICU) develop severe ARDS [1][2], making it the most common life-threatening condition associated with a SARS-CoV-2 infection [3]. The COVID-19 pandemic created new ways to demonstrate the effectiveness of VV-ECMO as a bridging strategy to gain valuable time, both for recovery and for the application of additional patient-specific therapies and treatment.

COVID-19 associated ARDS vs. ARDS of other causes:
Any impact on ECMO outcomes?

VV-ECMO was used early during the pandemic to treat the most severe forms of COVID-19 associated ARDS [7]. While some initial reports indicated high mortality [8], subsequent studies showed significantly more positive outcomes. Not surprisingly, ECMO results for ARDS caused by COVID-19 and other types of ARDS are not substantially different.

For example, the international cohort study conducted by the ELSO (Extracorporeal Life Support Organization) Registry showed an estimated cumulative hospital mortality of 37% for critically ill adults 90 days after initiation of ECMO, when conducted at experienced centers [9]. Based on 1.035 ECMO patients from 213 centers in 36 countries, this report sends an important message and allows for a general estimate of mortality in the context of COVID-19 infections supported with ECMO for the first time. Another retrospective observational study shows that for those patients who were considered not suitable for ECMO, the 90-day mortality rate was as high as 86%, comparing with patients who received ECMO support immediately or after optimization of the medical treatment, where mortality rates were 49% and 46%, respectively [20]. Other studies have reported comparable outcomes to previous observations [10][11][12][13] with regards to the effect of ECMO in patients with other causes of acute respiratory failure [4][5], although mortality rates partly vary over the course of the pandemic and in different countries [14][15][16][17][18].



COVID-19 associated ARDS
ARDS of other causes
Country Chile [13] France [11] USA [12] International [9] International [10] International [4] UK [5]
Study type Cohort study Retrospective cohort study Multi-center study Cohort study Meta-analysis Multi-center study Multi-center study
Patients 85 83 190 1.035 1.896 249 180
60d mortality 38% 31% 33% 37% 36% 40% 37%

Table 1: A study comparison between Covid-19 associated ARDS and ARDS of other causes

This overview shows the mortality rates of patients with COVID-19 associated ARDS across different countries. ECMO results do not drastically differ between COVID-19 and other causes of acute respiratory distress.

ECMO Covid-19; vv-ECMO; ECLS; ICU

The effect of ECMO availability on patient survival

During the COVID-19 pandemic, the number of patients with severe ARDS exceeded the capacity of healthcare facilities to provide ECMO therapy. In a prospective study from 2022, Gannon et al. [15] examined whether a healthcare system’s capacity to provide ECMO had an impact on the survival of patients with severe ARDS due to COVID-19. The authors analyzed consecutive patients with severe ARDS from a SARS-CoV-2 infection, who were referred for ECMO to a single center during an eight-month period in 2021. 90 patients were medically eligible to receive ECMO and were included in the study. 35 out of 90 patients received ECMO, while the remaining 55 patients did not receive ECMO due to the health system’s limited capacity to provide the therapy. As a result, 89.1% of patients who did not receive ECMO died before hospital discharge, compared to 42.9% of those who did receive ECMO (see Graph 1). Both groups were similar in terms of demographics, comorbidities, and ventilation settings.

Gannon study ECMO & Covid-19, graph.png

Graph 1: Cumulative proportion of patients who died before hospital discharge (Gannon et al., 2022) [15]

Although these results lacked randomization and had several other limitations, the Gannon study raises an important question: May the inability to provide ECMO to all eligible patients due to limited healthcare system resources have resulted in preventable deaths from ARDS?

Proven, lower mortality

In another large observational study from 2022, Urner et al. [19] quantified the effect of ECMO and its potential survival benefit. The study examined data from the COVID-19 Critical Care Consortium registry, including 7.345 adult patients from 30 countries. These patients were admitted to the ICU with a SARS-CoV-2 infection between January 2020 and August 2021. The study showed that mortality rates for patients receiving ECMO were 7.1% lower than those without ECMO intervention (see graph 2). Age, severity of hypoxemia, and duration and intensity of mechanical ventilation were found to be modifiers of treatment effectiveness.

ECMO & Covid-19; Urner; Venovenous extracorporeal membrane oxygenation in patients with acute covid-19 associated respiratory failure:  comparative effectiveness study

Graph 2: Results for Hospital Mortality (Urner et al., 2022) [19]

Again, within the limitations of observational data, the study indicates that ECMO would have improved outcomes if consistently provided to well-selected patients with more severe hypoxemia, or with exposure to higher intensities of mechanical ventilation.

What Have We Learned?

In patients with severe ARDS, ECMO has already in the past been proven to work and deliver lower mortality rates [4]. Likewise, recent data from the COVID-19 pandemic strongly indicate that even in stressful circumstances, COVID-19-associated ARDS can be efficiently treated with ECMO [3]. The available data seem to strongly support a potential mortality benefit, specifically for selected, severely ill patients [17].

Current evidence shows that certain factors increase the survival probability of patients, with VV-ECMO as a potential rescue procedure for COVID-19-associated ARDS. A younger age [3][9][16][17][18][19] and a rapid decision to initiate ECMO within 7 days [3][16] are independently associated with improved survival, as is performing ECMO in experienced centers with at least 30 cases per year [3] - a phenomenon that has also become evident in many other clinical scenarios [23]. The severity of hypoxemia [9][19], the intensity [19] and duration of mechanical ventilation [16][19] as well as optimal ARDS therapy before ECMO with the administration of neuromuscular blockers and prone positioning [3][9][16] proved to be additional influencing factors for the effectiveness of treatment. Comorbidities such as advanced cardiac, respiratory, or liver failure, irreversible organ damage and renal impairment prior to ECMO seem to be risk factors for bad clinical outcomes [3][9]

The individual, patient-centric decision to implement and manage ECMO correctly in patients with severe ARDS naturally remains complex, especially in the face of limited resources during a pandemic. The search for the sweet spot, or the "effective zone" in which ECMO can achieve its optimum effect has long been a concern for experts. "Don't blame the tool" comments Alain Vuylsteke from NHS Royal Papworth Hospital in Lancet [22]: "Selecting the right patient at the right time is based on clinical principles and experience, as well as availability. Clinicians carefully and subjectively weigh up the risks and benefits of starting ECMO for each patient. The turning point at which one is better than the other is unknown, even if the criteria have been well defined and are regularly reviewed [21]."

Therefore, experience with corresponding case quantity is a decisive factor. Special inclusion and exclusion criteria as well as a standardization of treatment regimens could be the key to smart patient selection [18]. Following expert consensus on this area [24] may help other centers to move forward in the implementation of this valuable therapeutic strategy. Experience is also a way of acquiring knowledge, and knowledge can be quantified, digitalized and shared nowadays at a very quick pace. Perhaps technology can help unexperienced centers to improve decision-making in patient selection in the near future.

Related Articles

  1. 1. Wu C et al. Risk Factors Associated With Acute Respiratory Distress Syndrome and Death in Patients With Coronavirus Disease 2019 Pneumonia in Wuhan, China. JAMA Internal Med. 2020;180(7):934-943

  2. 2. Li X et al. Extracorporeal Membrane Oxygenation for Coronavirus Disease 2019 in Shanghai, China. ASAIO J. 2020;66(5):475-481

  3. 3. Lebreton G et al. Extracorporeal membrane oxygenation network organization and clinical outcomes during the COVID-19 pandemic in Greater Paris, France: a multicentre cohort study. Lancet Respir Med. 2021;9(8):851-862.

  4. 4. Combes An et al. Extracorporeal Membrane Oxygenation for Severe Acute Respiratory Distress Syndrome. N Engl J Med 2018;378(21):1965-1975

  5. 5. Peek GJ et al. Efficacy and economic assessment of conventional ventilatory support versus extracorporeal membrane oxygenation for severe adult respiratory failure (CESAR): a multicentre randomized controlled trial. Lancet. 2009;374(9698):1351-1363

  6. 6. Munshi L et al. Venovenous extracorporeal membrane oxygenation for acute respiratory distress syndrome: a systematic review and meta-analysis. Lancet Respir Med. 2019;7(2):163-172

  7. 7. Wiersinga WJ, Prescott HC. What is COVID-19? JAMA. 2020;324(8):816

  8. 8. Henry BM, Lippi G. Poor survival with extracorporeal membrane oxygenation in acute respiratory distress syndrome (ARDS) due to coronavirus disease 2019 (COVID-19): Pooled analysis of early reports. J Crit Care. 2020;58:27-28

  9. 9. Barbaro et al. Extracorporeal membrane oxygenation support in COVID-19: an international cohort study of the Extracorporeal Life Support Organization registry. Lancet. 2020;396(10257):1071-1078

  10. 10. Ramanathan K et al. Extracorporeal membrane oxygenation for COVID-19: a systematic review and meta-analysis. Crit Care 2021;25:211

  11. 11. Schmidt M et al. Extracorporeal membrane oxygenation for severe acute respiratory distress syndrome associated with COVID-19: a retrospective cohort study. Lancet Respir Med. 2020;8(11):1121-1131

  12. 12. Shaefi S et al. Extracorporeal membrane oxygenation in patients with severe respiratory failure from COVID-19. Intensive Care Med. 2021;47(2):208-221

  13. 13. Diaz RA et al. Extracorporeal Membrane Oxygenation for COVID-19-associated Severe Acute Respiratory Distress Syndrome in Chile: A Nationwide Incidence and Cohort Study. Am J Respir Crit Care Med. 2021;204(1):34-43

  14. 14. Mustafa AK et al. Extracorporeal Membrane Oxygenation for Patients With COVID-19 in Severe Respiratory Failure. JAMA Surg. 2020;155(10):990-992

  15. 15. Gannon WD et al. Association between Availability of Extracorporeal Membrane Oxygenation and Mortality in Patients with COVID-19 Eligible for Extracorporeal Membrane Oxygenation: A Natural Experiment. Am J Respir Crit Care Med. 2022;205(11):1354-1357

  16. 16. Nesseler N, Fadel G, Mansour A, et al. Extracorporeal Membrane Oxygenation for Respiratory Failure Related to COVID-19: A Nationwide Cohort Study. Anesthesiology. 2022;136(5):732-748

  17. 17. Hall CA et al. Multi-institutional Analysis of 505 Patients With Coronavirus Disease-2019 Supported With Extracorporeal Membrane Oxygenation: Predictors of survival. Ann Thorac Surg. 2022;114(1):61-68

  18. 18. Karagiannidis C et al. High In-Hospital Mortality Rate in Patients with COVID-19 Receiving Extracorporeal Membrane Oxygenation in Germany: A Critical Analysis. Am J Respir Crit Care Med. 2021;204(8):991-994

  19. 19. Urner M et al. Venovenous extracorporeal membrane oxygenation in patients with acute COVID-19 associated respiratory failure: comparative efficacy study. BMJ. 2022;377:e068723

  20. 20. Levy D et al. Outcomes of Patients Denied Extracorporeal Membrane Oxygenation during the COVID-19 Pandemic in Greater Paris, France. Am J Respir Crit Care Med. 2021;204(8):994-997

  21. 21. Camporota L et al. Consensus on the referral and admission of patients with severe respiratory failure to the NHS ECMO service. Lancet Respir Med. 2021;9(2):e16-e17

  22. 22. Vuylsteke A. ECMO in COVID-19: do not blame the tool. Lancet. 2021;398(10307):1197-1199

  23. 23. Nguyen YL et al. The Volume Outcome Relationship in Critical Care: A Systematic Review and Meta-analysis. Chest. 2015;148(1):79-92

  24. 24. ELSO Guidelines:

    https://www.elso.org/portals/0/files/pdf/elso%20covid%20guidelines%20final.pdf
