PSG Biotech Quattroflow Diaphragm Pumps

Name: PSG Biotech Quattroflow Diaphragm Pumps
Brand: Getinge

Single-use & multi-use integrated smart pumps

Distributor Line: As part of HPNE’s partner portfolio, this product extends our ability to deliver complete and reliable bioprocessing solutions under Getinge.

The Quattroflow diaphragm pumps are utilized in biopharmaceutical processes such as chromatography and filtration; their seal-less design ensures the gentle transfer of shear-sensitive biologics, with disposable single-use options further eliminating the need for complex cleaning and sterilization between batches.

A gentle force in sterile pumping

Quattroflow pumps are purpose-built to ensure the integrity of high-value, shear-sensitive media across the bioprocessing workflow, making the Quattroflow technology critical for numerous upstream and downstream applications, including:

Filtration and separation, Tangential flow filtration: Recirculation of feed and retentate in membrane cassettes, hollow fiber, spiral wound, and ceramic elements.
Depth and sterile filtration: Serving as a gentle feed pump for filter cartridges and plate-and-frame depth filters.
Purification and metering
Chromatography: Precisely packing chromatography columns and consistent flow for separation processes.
General fluid transfer: as well as many other sensitive fluid transfers, recirculation, and metering applications.

Fluid transfer

4-piston quaternary diaphragm technology
Seal-less pump chamber
Low shear stress
Minimal particle generation
Low pulsation

Accuracy and control

Linear flow performance
Wide turndown ratio
Accurate & repeatable dosing
High flow stability
Volume & time dispensing

Process reliability

Self-priming design
Safe dry run
Available with a diaphragm sensor
Increased process uptime

User interface

Enlarged HMI touchscreen
Multiple operating modes (continuous, dispense, PID control)
Quick start-up
Updated alarm features
Ethernet connectivity

PSG Biotech Quattroflow Diaphragm Pump family

Quattroflow diaphragm pump range

The Quattroflow portfolio offers an extensive flow capacity range, ensuring that a suitable, low-shear solution is available for all key stages of the bioprocessing workflow—from lab-scale development to full commercial production. Leveraging the proprietary four-piston diaphragm technology, each model delivers a gentle, highly reproducible, and linear flow, with minimal pulsation and a negligible risk of product contact with non-wetted parts. As shown in the table below, the range extends from micro-dosing precision to high-volume transfer, providing scalability and performance.

Range comparison


	QF30	QF150	QF1200	QF2500	QF4400	QF5050	QF5K	QF10K	QF20K
Flow rate	0.001 – 0.5 LPM	0.02 – 3 LPM	0.1 – 20 LPM	0.42 – 41.67 LPM	0.83 – 83.33 LPM	0.83 – 83.33 LPM	0.83 – 100 LPM	8.33 – 166.67 LPM	16.67 – 266.67 LPM
Typical application scale	Benchtop, R&D, Micro-dosing	Pilot, Small-scale formulation	Pilot, Mid-scale filtration	Mid-scale chromato-graphy, TFF	Production, Large-scale TFF	Production, Large-scale transfer	Large production	Large production, Chromato-graphy	High-volume production/ transfer
Single or multi-use	Single-use	Multi-use	Multi-use	Multi-use	Multi-use	Multi-use	Multi-use	Multi-use	Multi-use
