Easily configure your glass autoclavable bioreactor to changing process demands
- Simple set-up and easy handling
- Wide range of volumes to fit many applications
- Easy cleanability by electropolished finish of the product
- Interchangeable modules to tailor the systems to research demands
The Applikon Bio is easy to upgrade if a change in research activities occurs, whether it involves cell culture applications or microbial culture applications. Because of the modularity and flexibility, you can always adapt the system to
changing process demands. This results in low initial investment and low running costs.
The stirred tank reactor (STR) is the most widely used bioreactor type. Getinge Applikon multi-use bioreactors and fermenters are available in 2 / 3 / 5 / 7 / 15 / 20 liter total volume.
Advances in bioreactor washing
The programmable Getinge Ultima Lancer labware washer with specialty washer rack for the multi-use 1-3 L bioreactors assures thorough cleaning, better reproducibility and reduced labor.
Watch the video to view how the Getinge Applikon bioreactors and Getinge Lancer washers bring you a holistic solution for lab applications.
This Applikon bioreactor straight in your lab
Are you interested in the multi-use Applikon bioreactor, and would you like to get a virtual sample right now? Try this bioreactor in Augmented Reality*.
Scan the QR code on your desktop with your mobile device or click on the link directly on the mobile device and discover how the Applikon Bio would be on your bench.
*View this page on an Augmented Reality (AR) compatible device. Augmented Reality (AR) adds digital elements to the camera of your smartphone, creating the illusion that holographic content is a part of a physical world around you.
The glass dished bottom vessels are made of borosilicate glass to guarantee:
- resistance to thermal shock
- excellent corrosion resistance
- smooth, non porous surface for easy cleaning
- optimal transparency for visual inspection of the culture
High quality parts
The system is built according to the specific demands of a process using an extensive array of high quality components. All metal parts of the bioreactor are constructed of stainless steel 316L. There are no welded parts in the bioreactor topplate, which simplifies the sterilization of the bioreactor after each run.
Up to 0.5 barg
The glass bioreactor vessels can be used up to 0.5 barg (7.5 psig) of overpressure.
|2 liter single wall||2.2||1.7||0.5||2.2||1.9|
|2 liter jacketed||2.2||1.7||0.5||2.2||1.9|
|3 liter single wall||3.1||2.7||0.5||1.9||1.5|
|3 liter jacketed||3.1||2.7||0.5||1.9||1.5|
|5 liter single wall||4.8||3.4||0.9||1.6||1.1|
|5 liter jacketed||4.8||3.4||0.9||1.6||1.1|
|7 liter single wall||6.8||5.4||1.5||2.2||1.8|
|7 liter jacketed||6.8||5.4||1.5||2.2||1.8|
|15 liter single wall||16.5||12||3.0||1.7||1.5|
|15 liter jacketed||18.2||12||3.0||1.5||1.2|
|20 liter single wall||23.4||16||3.0||2.4||2.0|
|Internal Diameter (mm)||Internal Height (mm)||Autoclave dimensions (WxH mm)|
|2 liter single wall||105||240||ø190 x 436|
|2 liter jacketed||105||240||ø219 x 486|
|3 liter single wall||130||240||ø190 x 436|
|3 liter jacketed||130||240||ø235 x 436|
|5 liter single wall||160||250||ø260 x 436|
|5 liter jacketed||160||250||ø260 x 480|
|7 liter single wall||160||350||ø260 x 600|
|7 liter jacketed||160||350||ø264 x 645|
|15 liter single wall||222||440||ø381 x 710|
|15 liter jacketed||240||440||ø391 x 740|
|20 liter single wall||222||620||ø381 x 900|
|Drive system||Direct drive, lipsealed or magnetically coupled|
|Stirrer speed (rpm)||Standard range is 50 - 1250
2 and 3 liter systems can be supplied with 2000 rpm motor
|Impellers||Rushton and marine with outside diameters 45 mm, 60 mm 75 mm or 85 mm|
|Gas sparger||Porous sparger or L-type sparger|
|Exhaust gas||Water cooled exhaust gas condenser|
|Sampling||Fixed height or height adjustable sample pipe with optional sampling system
Sample pipe internal diameters choices are: 1.7 mm, 4 mm, 6 mm or 10 mm
|Additions||Triple or single inlet ports and optional micro liquid injectors|
|pH||Measurement: 12 mm classic pH sensor|
|Control: via acid pump or CO2 gas (rotameter or MFC) in combination with alkali pump|
|DO2||Measurement: 12 mm classic polarographic DO2 sensor or LumiSens for 2-5 L
Control: via a combination of N2, Air, O2 (Rotameter or MFC) and agitation
|Temperature||Measurement: Pt-100 sensor in thermowell in topplate
Control: cooling and/or heating jacket via bioreactor wall or via internal heat exchanger
|Foam||Measurement: Height adjustable conductivity based foam sensor
Control: anti-foam addition pump
|Level||Measurement: Height adjustable conductivity based level sensor
Control: pump for liquid addition or removal
|Optional inlets||Septum, chemostat tube, liquid entry system|
The Applikon Bio is ideal for the following applications:
- Microbial cultures
- Cell cultures
- Continuous cultivation
