Easy to control your bioreactor
- Up to 6 Mass Flow Controllers
- Less maintenance due to brushless motor
- Powerful software features to simplify and optimize bioprocesses
Advanced user management enables you to create up to 21 users on 3 authorization levels. Back-ups, copies and predefined settings of configurations can simply be shared via USB. Extra flexibility is brought by additional analog and digital inputs / outputs.
The brushless motor requires virtually no maintenance, which saves you costs in the long term. It contains only one cable for the motor power and feedback and includes a motor controller. The ez2-Control comes with a motor support at the side of the device for easy operation.
Easily set, control and adapt your parameters, including pH, temperature, dissolved oxygen, agitation, foam, and level to optimize the bioprocess. It has total gas flow control to reduce shear stress for cell cultivations.
It is based on the same familiar Getinge Applikon control platform as the other controllers.
Advanced control strategies
The ez2-Control comes with selectable autotuning adaptive PID control for accurate control when process conditions change during the culture.
It has extended liquid additions options via (up to) 4 variable speed pumps. And it comes with enhanced gas addition strategies via (up to) 6 mass flow controllers.
The built-in web server allows the ez2-Control to be operated by any computer with a web browser: Microsoft Edge, Mozilla Firefox, Apple Safari or Google Chrome. Wireless devices like iPad, iPhone or Android tablets or phones can also be used to operate an ez2-Control.
Via the built-in web server enhanced parallel processing is accessible which allows the user to control multiple bioreactors in parallel.
The remote desktop support gives you access whenever and where ever you want.
|pH Sensor||Traditional electrochemical or Single-use
Measurement range: 0-14 pH, accuracy 0,01 pH
|DO sensor||Traditional Polarographic, LumiSens or Single-use
Measurement Range: 0-100% saturation, accuracy 0,1%
Range 2000 mV, accuracy +/- 1 mV, resolution 1 mV
Measurement Range: 0-150 °C accuracy 0,1°C
|Foam/level||Resistive based measurement|
|Optional||Biomass (Capacitance or optical density), offgas measurements, pressure|
|Additional I/O||Up to 8 Analog in and 4 Analog out
Up to 8 Digital In and 8 Digital out
|Gas||Up to 6 MFC’s with solenoid valves or
Up to 4 rotameters with solenoid valves
|Liquids||Up to 3 internal fixed speed pumps
Up to 4 external variable speed pumps
|Stirring||0-2000 rpm with feedback, accuracy 0,1% FS|
|Temperature||Heating blanket or internal Thermocircuilator
Cooling with cold water water valve
|Control hardware platform||Applikon proprietary|
|Control software platform||Applikon Firmware|
|Certifications||CE certified, GAMP compliant|
|21 CFR part 11 compatible||Yes|
|Communication & SCADA||Lucullus PIMS, DeltaV|
|Applikon OPC server available|
The Applikon ez2-Control is ideal for the following applications:
- Microbial and cell cultures
- Batch, Fed-Batch, Perfusion, and Continuous cultivation
- Autoclavable bioreactors up to 20 liter volume
- Single-use bioreactors
- Steam-in-place bioreactors
